Bearings
Automotive Bearings >>
Truck and Trailer Parts
| Boundary dimensions(mm) | Bearing Number | ||||
| d | D | L | E/D1 | F | XLB |
| 30.226 | 70.1 | 30.18 | 18.64 | 57.5 | 614007 |
| 34.99 | 70.1 | 30.07 | 9.7/16.1 | 41.28 | 614009 |
| 33.72 | 69 | 33.9 | 15.24/ | 42.5 | 614013 |
| 36.42 | 69 | 34 | 15.24/ | 42.5 | 614014 |
| 34.05 | 100 | 23.8 | 14.15 | 72.25 | 614015 |
| 31.75 | 67.31 | 39.73 | 32 | 45.95 | 614016 |
| 34.925 | 69 | 32.25 | 12.8/ | 41.27 | 614018 |
| 33.08 | 90 | 23 | 13 | 67.9 | 614022 |
| 33.07 | 80.62 | 40.26 | 25/11.99 | 77.29 | 614026 |
| 31.04 | 63.83 | 35.71 | 23.01 | 53.16 | 614031 |
| 29 | 57 | 31 | 21 | 47 | 614033 |
| 31.81 | 77.71 | 51.94 | /41.3 | 49.1 | 614036 |
| 34.93 | 67.05 | 48.23 | 12.8/31.75 | 41.27 | 614037 |
| 36.51 | 73.66 | 36.55 | /24.8 | 60.45 | 614038 |
| 33 | 74.15 | 28.45 | 22 | 70.23 | 614043 |
| 31.75 | 70.4 | 43 | 35.5 | 45.9 | 614044 |
| 33.08 | 90 | 23 | 13 | 67.9 | 614047 |
| 28 | 57 | 24.5 | 614050 | ||
| 31.75 | 71.88 | 34.49 | 27 | 45.85 | 614053 |
| 31.81 | 77.72 | 55.56 | 41.275 | 49.11 | 614054 |
| 3.19 | 73.7 | 35 | 25 | 70.5 | 614056 |
| 33.15 | 80.01 | 32 | 23.01 | 68.4 | 614059 |
| 36.106 | 81.46 | 42.37 | 27/11.99 | 77.29 | 614067 |
| 31.115 | 69.85 | 38.608 | 26.29 | 53.213 | 614077 |
| 28.067 | 59.69 | 31.877 | 21.844 | 30.28 | 614082 |
| 34.99 | 70.1 | 30.7 | 12.1/16.5 | 41.275 | 614083 |
| 35.64 | 83.95 | 33.909 | 24.92 | 79.375 | 614084 |
| 35 | 76 | 40.5 | 30 | 44 | 614086 |
| 36.45 | 77.72 | 51 | 41.275 | 49.2 | 614093 |
| 37 | 74 | 43.5 | 614107 | ||
| 31.8 | 77.47 | 24.61 | 17.37 | 55.7 | 614108 |
| 28 | 57.15 | 27.5 | 22.51 | 41 | 614110 |
| 31.78 | 70.4 | 33.8 | 21.1 | 60 | 614126 |
| 29.26 | 62.84 | 33.78 | 21/11 | 38 | 614128 |
| 28 | 57 | 29 | 22.5 | 45 | 614145 |
| 33 | 81 | 31 | 22/16.69 | 79.25 | 614152 |
| 35 | 75 | 33.8 | RCT359SA9 | ||
| 45 | 73.6 | 18 | RCT45-1S |
