Boundary dimensions(mm)													Mass	Bearing Number
Da	o	g	p	q	s	b	K	e	a	w	l	j	Kg	XLB
47	16	10	51	32	19	51	13.5	76.2	89	94	21	32	0.48	ST204
52	16	10	51	32	19	51	13.5	76.2	89	97	24	32	0.60	ST205
62	16	10	56	37	22	57	13.5	89	102	113	28	37	0.80	ST206
72	16	13	64	37	22	64	13.5	89	102	129	30	37	1.12	ST207
80	19	16	83	49	29	83	17.5	102	114	144	33	49	1.62	ST208
85	19	16	83	49	29	83	17.5	102	117	145	35	49	1.73	ST209
90	19	16	83	49	29	86	17.5	102	117	151	37	49	1.90	ST210
100	25	19	102	64	35	95	22	130	146	171	38	64	3.10	ST211
110	32	19	102	64	35	102	22	130	146	194	42	64	3.60	ST212
120	32	21	111	70	41	121	27	151	167	224	44	70	5.40	ST213
125	32	21	111	70	41	121	27	151	167	224	46	70	6.05	ST214
130	32	21	111	70	41	121	27	151	167	232	48	70	6.45	ST215
