| Dimensions (mm) | Basic load ratings (kN) | Cone | Cup | Mass (Kg) | Bearing No. | ||||||
| d | D | T | Cr | Cor | B | R | C | r | (Approx.) | XLB | ISO 355 |
| 80 | 140 | 35.25 | 199 | 265 | 33 | 2.5 | 28 | 2 | 2.18 | 32216 | T3EC080 |
| 90 | 160 | 42.5 | 262 | 360 | 40 | 2.5 | 34 | 2 | 3.49 | 32218 | T3FC090 |
| Dimensions(mm) | Basic load ratings (kN) | Bearing No. | |||||||
| Cone | Cup | T | |||||||
| d | B | R | D | C | r | Cr | Cor | XLB | |
| 89.974 | 40.000 | 3.5 | 146.975 | 32.500 | 7 | 40.000 | 227 | 340 | HM218248/10 |
| 90.000 | 34.000 | 2.5 | JM718149 | ||||||
| 90.000 | 34.000 | 2.5 | 145.000 | 27.000 | 3 | 35.000 | 189 | 279 | JM718149/10 |
| 88.900 | 48.260 | 3.3 | 759 | ||||||
| 88.900 | 48.260 | 3.3 | 161.925 | 38.100 | 3.5 | 47.625 | 270 | 385 | 759/752 |
| 89.974 | 40.000 | 3.5 | HM218248 | ||||||
| 80.962 | 46.672 | 3.3 | 150.089 | 36.512 | 5 | 44.450 | 261 | 360 | 740/742 |
| 85.026 | 46.672 | 3.3 | 749 | ||||||
| 85.026 | 46.672 | 3.3 | 150.089 | 36.512 | 3.5 | 44.450 | 261 | 360 | 749/742 |
| 82.550 | 41.275 | 3.3 | 663 | ||||||
| 82.550 | 41.275 | 3.3 | 146.050 | 31.750 | 3.5 | 41.275 | 206 | 295 | 663/653 |
| 80.962 | 46.672 | 3.3 | 740 | ||||||
| 82.550 | 36.098 | 3.3 | 580 | ||||||
| 82.550 | 36.098 | 3.3 | 139.992 | 28.575 | 3.5 | 36.512 | 178 | 265 | 580/572 |
| 95.250 | 36.322 | 3.3 | 594 | ||||||
