| Bearing Number | Boundary dimensions(mm) | ||||||||||
| KML | D | L | A | d | B | C | d1 | d2 | S1 | S2 | E |
| WR1530085D | 30.00 | 38.90 | 85.00 | 15.008 | 13.10 | 33.00 | 12.038 | 32.00 | |||
| WR1530087D | 30.00 | 38.90 | 87.00 | 15.008 | 15.00 | 33.10 | 12.055 | 30.20 | |||
| WR1630096 | 30.00 | 38.90 | 95.45 | 15.918 | 14.32 | 42.32 | 39.32 | ||||
| WR1630096D | 30.00 | 33.40 | 96.25 | 15.918 | 14.94 | 47.91 | 12.000 | 45.40 | |||
| WR1630096D-1 | 30.00 | 33.80 | 96.30 | 15.918 | 14.60 | 47.90 | 12.038 | 46.40 | |||
| WR1630096D-2 | 30.00 | 38.90 | 95.50 | 15.918 | 14.18 | 42.42 | 12.037 | 40.39 | |||
| WR1630096D-3 | 30.00 | 38.90 | 95.63 | 15.918 | 17.53 | 39.20 | 12.000 | 34.90 | |||
| WR1630096D-4 | 30.00 | 38.90 | 96.00 | 15.918 | 15.00 | 42.10 | 12.038 | 37.50 | |||
| WR1630096D-5 | 30.00 | 38.90 | 96.40 | 15.918 | 18.00 | 39.50 | 12.052 | 36.60 | |||
| WR1630097D | 30.00 | 38.90 | 96.49 | 15.918 | 16.44 | 41.15 | 12.000 | 38.51 | |||
| WR1630097D-1 | 30.00 | 38.90 | 96.50 | 15.918 | 15.35 | 42.25 | 12.738 | 40.00 | |||
| WR1630098 | 30.00 | 38.90 | 98.00 | 16.000 | 18.10 | 41.00 | 38.00 | ||||
| WR1630098D | 30.00 | 38.90 | 97.51 | 15.918 | 19.51 | 39.10 | 12.037 | 37.31 | |||
| WR1630098D-1 | 30.00 | 38.90 | 98.00 | 15.918 | 17.00 | 42.10 | 12.000 | 40.00 | |||
| WR1630099 | 30.00 | 34.50 | 99.10 | 15.918 | 18.90 | 45.70 | |||||
| WR1630099D-1 | 30.00 | 38.90 | 98.78 | 15.918 | 18.42 | 41.46 | 12.052 | 38.90 | |||
| WR1630099D-2 | 30.00 | 38.90 | 98.79 | 15.918 | 18.43 | 41.46 | 12.038 | 39.46 | |||
| WR1630100D | 30.00 | 38.90 | 99.85 | 15.918 | 10.50 | 50.45 | 12.038 | 43.30 | |||
| WR1630100D-1 | 30.00 | 38.90 | 99.85 | 15.918 | 10.81 | 50.14 | 12.037 | 43.31 | |||
| WR1630100D-2 | 30.00 | 46.00 | 99.54 | 15.918 | 16.89 | 36.65 | 12.000 | 33.55 | |||
| WR1630100DD | 30.00 | 38.90 | 99.49 | 15.918 | 16.47 | 44.12 | 12.000 | 12.000 | 14.61 | 41.28 | |
| WR1630101 | 30.00 | 38.90 | 100.85 | 15.918 | 16.00 | 45.95 | |||||
| WR1630101-1 | 30.00 | 38.90 | 100.99 | 15.918 | 25.25 | 36.84 | 31.14 | ||||
| WR1630101D | 30.00 | 27.00 | 101.00 | 15.918 | 31.80 | 42.20 | 12.000 | 40.70 | |||
| WR1630101D-1 | 30.00 | 38.90 | 100.51 | 15.918 | 18.01 | 43.60 | 12.000 | 33.50 | |||
| WR1630101D-2 | 30.00 | 38.90 | 101.00 | 15.918 | 24.99 | 37.11 | 12.000 | 34.98 | |||
| WR1630101DD | 30.00 | 38.90 | 101.09 | 15.918 | 22.84 | 39.35 | 12.002 | 12.042 | 19.84 | 38.61 | |
| WR1630102 | 30.00 | 36.50 | 101.50 | 15.951 | 20.00 | 45.00 | |||||
| WR1630102-1 | 30.00 | 38.90 | 102.00 | 15.918 | 17.00 | 46.10 | 41.30 | ||||
| WR1630102-2 | 30.003 | 36.50 | 101.50 | 15.918 | 26.00 | 39.00 | |||||
| WR1630102D | 30.00 | 34.00 | 101.55 | 15.918 | 22.05 | 45.50 | 12.000 | 43.38 | |||
| WR1630102D-1 | 30.00 | 38.90 | 102.24 | 15.918 | 23.72 | 39.62 | 12.000 | 38.10 | |||
| WR1630103 | 30.00 | 38.90 | 103.00 | 16.000 | 27.10 | 37.00 | |||||
| WR1630103-1 | 30.00 | 38.90 | 103.12 | 15.918 | 27.92 | 36.30 | 31.47 | ||||
| WR1630103D | 30.00 | 38.90 | 103.00 | 15.918 | 16.50 | 47.60 | 12.000 | 45.30 | |||
| WR1630103D-1 | 30.00 | 38.90 | 103.02 | 15.918 | 16.54 | 47.58 | 12.000 | 44.86 | |||
| WR1630103D-2 | 30.00 | 38.90 | 103.33 | 15.918 | 18.54 | 45.89 | 12.738 | 43.79 | |||
| WR1630104 | 30.00 | 34.50 | 104.20 | 15.918 | 19.00 | 50.70 | |||||
| WR1630104D | 30.00 | 38.90 | 103.50 | 15.918 | 19.50 | 45.10 | 12.038 | 43.16 | |||
| WR1630104D-1 | 30.00 | 38.90 | 103.99 | 15.918 | 16.99 | 48.10 | 12.000 | 46.69 |
| WR1630104D-2 | 30.00 | 38.90 | 104.00 | 15.918 | 20.00 | 45.10 | 12.038 | 42.50 | |||
| WR1630104D-3 | 30.00 | 38.90 | 104.00 | 15.918 | 19.70 | 45.40 | 12.000 | 43.00 | |||
| WR1630105 | 30.00 | 38.90 | 105.41 | 15.918 | 20.31 | 46.20 | 41.38 | ||||
| WR1630105D | 30.00 | 38.90 | 104.55 | 15.939 | 20.93 | 44.72 | 12.037 | 42.62 | |||
| WR1630105D-1 | 30.00 | 38.90 | 105.00 | 15.918 | 30.70 | 35.40 | 12.000 | 32.00 | |||
| WR1630106 | 30.00 | 38.90 | 105.97 | 15.918 | 21.06 | 46.01 | 40.79 | ||||
| WR1630106-1 | 30.00 | 38.90 | 106.00 | 16.000 | 26.10 | 41.00 | 38.00 | ||||
| WR1630106-2 | 30.00 | 38.90 | 106.12 | 15.918 | 29.69 | 37.53 | 30.78 | ||||
| WR1630106D | 30.00 | 38.90 | 106.00 | 15.918 | 23.05 | 44.05 | 12.038 | 39.60 | |||
| WR1630106D-1 | 30.00 | 38.90 | 106.17 | 15.918 | 25.13 | 42.14 | 12.738 | 40.00 | |||
| WR1630106D-2 | 30.00 | 38.90 | 106.20 | 15.918 | 18.43 | 48.87 | 12.000 | 41.00 | |||
| WR1630106DD | 30.00 | 38.90 | 105.50 | 15.92 | 16.50 | 50.10 | 12.000 | 12.000 | 14.50 | 48.40 | |
| WR1630107 | 30.00 | 38.90 | 106.50 | 16.000 | 20.10 | 47.50 | |||||
| WR1630107-1 | 30.00 | 38.90 | 106.50 | 15.918 | 20.10 | 47.50 | |||||
| WR1630107-2 | 30.00 | 38.90 | 107.39 | 15.918 | 23.05 | 45.44 | 44.04 | ||||
| WR1630107D | 30.00 | 38.90 | 106.50 | 15.918 | 17.50 | 50.10 | 12.000 | 48.00 | |||
| WR1630107D-1 | 30.00 | 38.90 | 106.50 | 15.918 | 21.96 | 45.64 | 12.037 | 43.64 | |||
| WR1630107D-2 | 30.00 | 38.90 | 107.39 | 15.918 | 18.67 | 49.82 | 12.000 | 45.14 | |||
| WR1630108D | 30.00 | 38.90 | 108.30 | 15.918 | 18.40 | 51.00 | 12.038 | 48.00 | |||
| WR1630109D | 30.00 | 38.90 | 108.60 | 15.92 | 18.50 | 51.20 | 12.04 | 48.20 |
